Crankshaft sensor install on clio 3 rs200

[porka987s]

Hi all,

Trying to replace my crankshaft sensor. Got under the car, and removed with a 10mm what I thought was the old crankshaft sensor.

I opened the replacement, part number 82 000513668, but the head of the connector looks slightly different, and therefore doesn't connect to the plug...

I looked at the part number for the old part (well what I think is the old crank sensor), and the brand is 'continental' and some other random part number..

New part on left, compared to old part on right.

Any one have any ideas ? Or did I just remove something that wasn't the CAS (and looks similar), in which case I can't for the life of me, locate where it is.

Thanks!!!



[porka987s]

The thing I removed has a part number pa66gf30, made by 'continental' (lol)



[suj]

I'm pretty sure there were 2 different types of crankshaft sensors depending on year of manufacturing of the car.
There is only 1 sensor where the crankshaft is on gearbox, so you have removed the correct part.

Is it a genuine part that you bought (I know the old one was continental)?



[DS197]

I believe there are two different crank sensors each of which will have a different part number.



[porka987s]

I'm pretty sure there were 2 different types of crankshaft sensors depending on year of manufacturing of the car.
There is only 1 sensor where the crankshaft is on gearbox, so you have removed the correct part.

Is it a genuine part that you bought (I know the old one was continental)?

Yeah replacement part says renault czech Republic with said part number. I got it from renaultparts.co.uk.

Hmm..



[porka987s]

I believe there are two different crank sensors each of which will have a different part number.

Hmm maybe I have the wrong one, do you know where or how to locate the other sensor ?thx



[suj]

Yeah replacement part says renault czech Republic with said part number. I got it from renaultparts.co.uk.

Hmm..

I assume you meant: https://www.renaultpartsdirect.co.uk/
If so contact them with your car reg / the pics you showed of plugs, they can then swap for the correct part.



[porka987s]

I assume you meant: https://www.renaultpartsdirect.co.uk/
If so contact them with your car reg / the pics you showed of plugs, they can then swap for the correct part.

Yes these guys,sorry.

Yes good shout. Sucks that I'm all the way in Australia though!



[suj]

Yes these guys,sorry.

Yes good shout. Sucks that I'm all the way in Australia though!

Yeah it's a shame, but the guys at RPD are great so they'll sort you out for the correct part.
@Onrus can you help Porka with parts in Australia?



[DS197]

Parts numbers from an old thread on here are below, I’d just be aware of the fact that the part number(s) may have been superseded although one seems to match the one you’ve given.


Markings are

8200513668 - P/N 8200513668

or

A2C53255631 - P/N 8200746509



[porka987s]

Ahh thanks both!! Very helpful, will hit up renaultpartsdirect again..



[turkie172]

The TDC sensor on the gearbox and yes there are two types of gearbox sensor looks like one is magnetic and the other induction



[Onrus]

I order everything from the UK



[Onrus]

http://fb.com/RenaultSportParts | eBay Stores

We sell only new original and genuine parts Renault Sport ... http://fb.com/RenaultSportParts

www.ebay.com.au



[Onrus]

This seller has heaps of stuff



[Abdulla Ali Al Ali]

I'm from United Arab Emirates and my sources for Genuine Renault Parts are:

1. https://eurofrance24.com/

2. https://www.autodoc.co.uk/

3. https://www.renaultgenuineparts.com/

The first two websites are the fastest upon part's availability.

for your future considerations.
